DESCRIPTION
Cube 100S adopts energy dispersive X-ray fluorescence analysis technology. It is a portable and easy-to-use analytical instrument specially designed for on-site rapid analysis and measurement of sulfur content in various fuel oils by maritime and other related departments. The analyzer integrates an industrial custom-level Windows CE7.0 operating system to realize intelligent integrated operation and more convenient operation; on-site ship information, oil product information and other information input, test results and other information printing can be easily realized without a computer on site Function.
Cube 100S has extremely flexible analysis software inside, which can quickly analyze and detect the sulfur content in various fuel oils, and its function is comparable to a mobile laboratory. The device can provide users with operational performance and safety features comparable to traditional desktop EDXRF (energy dispersive fluorescent X-ray), and at the same time has the advantages of high cost performance and ruggedness of portable XRF technology analyzers; it is safer to operate than handheld , Lighter and more portable than traditional desktops.
Whether in the laboratory or outdoors, this portable X-ray analyzer can be operated quickly and conveniently, which helps users take immediate measures based on on-site analysis results.
Cube100S Plus is the latest Sulfur Analyzer from LABOAO. It meets the below international standards:
ASTM D 4294
ASTMD2262
ASTM D 6445
ISO 20847
ISO 8754
IP 336
IP 531
Application Fields:
Petrochemicals
Crude Oils
Liquid element analysis
FEATURES
1. Small and portable. You can take it to any place for the measurement.
2. With a built-in PDA and no need additional computer.
3. Close sample test distance improves test accuracy
4. Rapid analysis, with test result delivered within 50s at minimum
5. The same sample test height ensures test accuracy, saves standard sample and needs no special sampling tools
6. Top lighting design avoids X-ray tube and Be window of the detector to be polluted by sample volatilization. It can test light oils like gasoline, diesel with higher accuracy
7. High excitation efficiency side-window W Target X-ray tube, large area SDD detector, together with good dissipation capability ensure the high test stability
8. X-ray radiation shielding design ensures operators safety during operation
SPECIFICATIONS
Model | Cube 100S |
Measurement range | From P to U |
Testing samples | Solid, liquid and powder |
Content range | 30ppm—99.99% |
Testing method | EDXRF |
Detector | SDD detector, the lowest resolution reach to 125eV |
Working Temperature | -20℃~+50℃ |
Humidity | ≤90% |
Detection limit | 20ppm for Sulfur in fuel oil |
Operation | One key test |
Testing time | 30-130S |
Size | 212*258*258mm |
Weight | <4.5kg |
Measurement range | From P to U |
Testing samples | Solid, liquid and powder |
CONFIGURATION LIST
Detector | SDD detector |
X-ray tube | 4W micro X-ray tube |
Collimator | Ф4mm |
Sample Chamber | X-ray from bottom |
Radiation Safety system | The high voltage will be off when open the machine lid |
Sample placement | reusable membrane sample cup, testing sample directly |
Report print | by EXCEL file or portable Bluetooth printer (optional) |
Carrying case | Multi-function instrument protection case, convenient for carrying |
