Experimental Spray Freeze Dryer Experimental Spray Freeze Dryer Experimental Spray Freeze Dryer
Experimental Spray Freeze Dryer Experimental Spray Freeze Dryer Experimental Spray Freeze Dryer

Experimental Spray Freeze Dryer

LFSD-1 Experimental spray freeze dryer is an original product carefully developed by our company combining spray drying technology and vacuum freeze drying technology. Since the product came out, we have been steadily improving in function, performance and ease of use, spray freeze drying The processing capacity of each batch of the machine is 2000ML/time, and the drying time of some materials does not exceed 5 hours. The processing capacity of each batch of the customized spray freeze dryer reaches 5000ML/time and 10L/time. A series of spray freeze-dried products tried in the pilot test.
  • BrandLABOAO
  • ModelLFSD-1
  • PortAny port in China
  • PackagePlywood case package
Payment More
We also supports L/C、D/A、D/P、Western Union、MoneyGram、Discover payments for offline orders.
Download

DESCRIPTION

LFSD-1 Laboratory refrigerated spray dryer is suitable for low temperature drying of heat-sensitive, viscous, active materials and materials with high sugar content, such as natural product extracts of Chinese herbal medicine, dairy products, biological preparations, enzyme preparations, fruit juice, polymer materials Wait.


FEATURES

1. LFSD-1 The laboratory spray freeze dryer organically combines spray drying and vacuum freeze drying. The drying time required is extremely short, and the drying time of some materials does not exceed 5 hours (2000ML/time), which greatly shortens the traditional vacuum drying time. Freeze-drying time, and the dried material is a powdery solid, and the original biological and chemical properties of the spray-freeze-dried items are basically unchanged, and it is easy to store for a long time;

2. LFSD-1 The laboratory spray freeze dryer adopts an air-cooled condensing type fully enclosed compressor refrigeration system, which has rapid refrigeration, low freezer temperature, strong water absorption capacity, and digital display of temperature and vacuum degree, which is accurate and intuitive;

3. Freeze spray-dried items are naturally heated and sublimated by air to maintain the safety of samples;

4. The main unit is equipped with a vacuum pump power plug, no need to connect another power supply, and it is easy to use;

5. The vacuum connection adopts the international standard clamp, which is convenient and reliable;

6. Stable performance, easy operation and low noise;

7. LFSD-1 Laboratory spray freeze dryer compared to traditional freeze dryer: it can quickly freeze dry liquid materials that are easy to stick to walls and contain organic substances (juice, Chinese medicine extract, etc.), and the dried finished product is in a granular state, with good fluidity and granularity The particle size is adjustable within a certain range.


SPECIFICATIONS

Model

LFSD-1

Drying Capacity

1500ml/Time, Each Drying Time Is Less Than 6   Hours (From Feeding To Discharging)

Spray Freezing Temperature

-20-40°C

Cold Trap Temperature

≤-60°C

Vacuum Pump Power

2Kw

Vacuum Pressure

<20Pa

Spray Pressure

2-5Bar (Adjustable)

Compressed Air

4.2 m³ /h

Spray Head Type

Two-Fluid

Nozzle

Standard 0.7mm/(0.5/1.0/1.5/2.0mm Optional)

Body Material

Sus 304 Stainless Steel

Operating Mode

Automatic / Manual

Seals

Silica Gel

Vacuum Display

Number

Show

7-Inch Lcd Display With Usb Interface

Sample Safety

Vacuum Cryogenic Mode

Particle Size After Drying

120um


WHY CHOOSE US

  1. Factory direct sales with competitive price.
  2. Premium quality with CE & ISO certification.
  3. Strong product OEM & ODM customization capability.
  4. Promise production & on-time delivery.
  5. Perfect after-sales service, free product accessories.
  6. 15 years of experience in R&D and production of freeze spray dryer machine.
laboao certification

OUR FACTORY

We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.

laboao factory

PACKAGING & SHIPPING

Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.

laboao packaging and shipping

CUSTOMER CASES

Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe LABOAO, we grow together!

laboao customer cases

AFTER-SALE WARRANTY


Authenticity GuaranteedWe assure you purchase our products are 100% certified products.
24*7Hours ServiceProvide 7*24 hours service telephone & support email to help you solve problems quickly.
Technical SupportProvide equipment installation, adjustment, operation training, etc.
1 Year WarrantyFree maintenance and accessories within warranty period(not caused by human factors).
