Rotary vane vacuum pump works on a positive-displacement pumping principle. The design consists of a rotor, which is mounted eccentrically inside a cylindrical housing or stator. Blades, mounted inside the rotor, move in and out due to centrifugal force following the internal surface of the housing. A more detailed description of the operating principle of an oil lubricated and a dry running rotary vane pump can be seen further in this article.
1. With four patents.
2. Designed with corrosion resistance materials.
3. With less accessories, quick release.
4. Anti oil-return initiatively, to ensure no oil-return if being shut down.
5. With 2kinds of gas ballast to meet with different needs.
6. Working smoothly under the high pressure.
7. Semiconductor, Spatial simulation, The pharmaceutical R&D, Metallurgy, Chemical engineering, Vacuum furnace, Vacuum coating, Lamp and lamp tube manufacturing, Analysis of the engineering.
Model | T8 | T6 | T24 | T30 | T40 | T60 |
50Hz Nominal pumping speed M³/h(L/s) | 10/2 | 17/4 | 24/6 | 31/8 | 42/11 | 63/17 |
50Hz Pumping speed M³/h(L/s) | 8/2 | 15/4.3 | 23/6 | 29/8 | 40/11 | 60/16 |
Partial ultimate pressure without gas ballast (Pa) | 5x10-2 | 5x10-2 | 5x10-2 | 5x10-2 | 4x10-2 | 4x10-2 |
Total ultimate pressure without gas ballast (Pa) | 1 | |||||
Total ultimate pressure with gas ballast (Pa) | 6 | |||||
Vapour allowed pressure (Pa) | 20 | 20 | 20 | 25 | 25 | 25 |
Vapour pumping ability (g/h) | 230 | 230 | 300 | 300 | 1000 | 1100 |
Oil capacity (min/max)L | 1.5/2 | 1.5/2 | 1.5/2 | 1.6/2.2 | 3.5/4.5 | 4/5 |
Noise level (gas ballast close/open)(db a) | 58/60 | 60/62 | 60/62 | 60/62 | 60/62 | 60/62 |
Ambient temperature ℃ | 5-45 | |||||
Connector | KF25 | KF25 | KF25 | KF25 | KF40 | KF40 |
Power supply | Single/3phase | 3phase | ||||
Power rating (kw | 0.37 | 0.55 | 0.75 | 0.75 | 1.1 | 1.5 |
Dimensions (mm) | 520x175x285 | 540x175x285 | 564x175x285 | 584x175x285 | 660x234x350 | 720x234x350 |
Weight(without oil) kg | 33 | 36 | 38 | 40 | 68 | 75 |
We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.
Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.
Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe LABOAO, we grow together!
