UV VIS Spectrophotometer For Tank Washing Water

UV VIS Spectrophotometer For Tank Washing Water

This UV-Vis spectrophotometer is specially designed to test the water quality on board, especially for tank washing water.

BrandLABOAO
ModelLU-T21
PortAny port in China
PackagePlywood case package

GET A QUOTE EMAIL

Payment More

We also supports L/C、D/A、D/P、Western Union、MoneyGram、Discover payments for offline orders.

Download

DESCRIPTION

This UV-Vis photometer is specially used to detect the water quality on ships. The main detection items of wall wash are APHA Color Test, Inorganic Chloride Test, Water Miscibility Test , Permanganate Time Test etc.

FEATURES

1.Monochromator with single-beam grating optical path structure, good stability, reproducibility and accuracy.

2.Advanced ARM microcomputer technology, excellent electronic circuit and signal processing, stable and reliable data, U disk data storage and export, software one-key upgrade, bluetooth printing and other data output.

3.Integrated aviation-grade aluminum alloy substrate and machined reflector base ensure long-term stability of the optical path.

4.7-inch color large-screen graphic LCD display, combined with the design of the navigation menu interface, the operation commands are clear, and it has special functions to prevent users from making mistakes. able to operate.

5.Strict manufacturing process and 32 key quality control points make each instrument durable.

6.Deuterium lamps, tungsten lamps, photocells, precision screw rods and other key components are selected from well-known and imported brands to ensure reliable instrument quality.

7.Four-slot 10-50mm universal adjustable manual sample rack, convenient for testing cuvettes of different specifications.

8.Independently designed deuterium lamp, tungsten lamp replacement window, flange positioning structure, easy to replace.

SPECIFICATIONS

Model	LU-T21
Optical system	Single beam; 1200/mm imported holographic grating
Wavelength range	190-1100 nm
Spectral Bandwidth	2 nm
Maximum allowable error of wavelength	±0.5 nm
Wavelength repeatability	≤0.1 nm
Maximum allowable error of transmittance (%T)	±0.3%T; ±0.002Abs (0-0.5Abs); ±0.004Abs (0.5-1.0Abs)
Transmittance repeatability (%T)	±0.1%T; ±0.001Abs (0-0.5Abs); ±0.002Abs (0.5-1.0Abs)
%0 line and 100% line noise (%T)	0% line 0.2/100% line 0.3
Drift	≤0.2 %T
Baseline flatness	≤0.001 Abs
Stray light (%T)	≤0.03 @220nm and 360nm
Supply voltage adaptability	≤0.2%T
Photometric range	0-200%T, -0.301-3A, 0-9999C(0-9999F)
Test Modes	Transmission, Reflection, Absorbance, Concentration, Energy
Light source	deuterium lamp + tungsten lamp
Display	7 inch touch screen display (resolution 800*480)
System language	Chinese, English, Russian, Spanish
Software upgrade	support U disk one-key upgrade
Data output	U disk, Bluetooth, USB software upload
Data output format	CSV
Operation Mode	Touch Screen
Sample Holder	Four-slot 10-50mm Universal Adjustable Manual Sample Holder
Host function	basic+quantitative+qualitative+time+DNA+multi-wavelength
Printer	Optional, support Bluetooth printing
Power supply range	AC90～250V/ 50～60Hz
Dimensions (L×W×H)mm	470×330×210
Weight	12kg

WHY CHOOSE US

Factory direct sales with competitive price.
Premium quality with CE & ISO certification.
Strong product OEM & ODM customization capability.
Promise production & on-time delivery.
Perfect after-sales service, free product accessories.
15 years of experience in R&D and production of uv-vis spectrophotometer machine.

OUR FACTORY

We have a standard production workshop and a complete production team. They always produce a serious and responsible attitude to produce each product. Our R&D team is made up of multi-aspects professional engineers such as design engineer,technology specialist ,qualified specialist and process control manager, etc. Our qualified specialists strictly realize the process comprehensive supervision based on our quality process control system, which contains products design, research and development, test, production, quality inspection and packaging.

PACKAGING & SHIPPING

Our product packaging has been proven over the long term and we usually have plywood boxes or cartons with trays. We will arrange the appropriate packaging according to the weight and size of the goods. Of course, you can also choose the packaging form.

CUSTOMER CASES

Our laboratory instruments and equipment are used in many scientific laboratories, scientific research institutions, universities, hospitals, centers for disease control and other institutions, and are combined with many well-known biopharmaceuticals, new energy, electronics companies, food processing, environmental protection, etc. Enterprise cooperation, our stable and reliable products are exported to more than 120 countries around the world, and have been highly recognized by them, believe LABOAO, we grow together!
