Recirculating Chiller Heater including: cooling function, heating function circulation system. It is composed of refrigeration unit, heating unit, circulation system and control system. Refrigeration part is mechanically refrigerated by a fully enclosed compressor, composed of plate heat exchangers, expansion valves, and pressure protectors to meet the cooling requirements.
  • BrandLABOAO
  • ModelLGD-10/20 LGD-10/30 LGD-10/40 LGD-10/80
  • PortAny port in China
  • PackagePlywood case package
Payment More
We also supports L/C、D/A、D/P、Western Union、MoneyGram、Discover payments for offline orders.
Download

DESCRIPTION

Heating part is the use of electric heating tubes to heat the circulating fluid. And through the built-in circulating pump and the external circulating pipeline, the refrigerant or heat medium is transported to the interlayer of the supporting equipment, which indirectly cools and heats the materials in the reactor.

During external circulation, connect the upper outlet pipe of the product to the lower inlet pipe of the kettle body, and the circulating fluid will return to the lower return port of the product through the pipe from the upper circulation port to form a complete circulation space.

FEATURES

1. The temperature accuracy is generally ±1°C, and an external sensor can be connected (the temperature difference accuracy is generally ±0.5°C).

2. The maximum temperature limit to prevent the equipment from losing control [If the maximum temperature of the equipment is exceeded, the equipment will automatically power off.

3. Has power supply protection.

4. Compressor overheating protection, the compressor will stop working when the compressor withstand limit is reached.

5. Water cooling has water flow and low water pressure protection.

6. All compressors are imported compressors (France, Denmark).

SPECIFICATIONS

Model

LGD-10/20

LGD-10/30

LGD-10/40

LGD-10/80

Operating temperature range

-20   +200

-30+200

-40+200

-80+200

Optimum ambient temperature

535

535

535

535

Environment humidity

≤70ventilation

≤70ventilation

≤70ventilation

≤70ventilation

Power supply

1phase   220V/50HZ

1phase   220V/50HZ

three   phase380V/50HZ

three   phase380V/50HZ

Safety protection

Delay, overcurrent, overheating, overtemperature

Delay, overcurrent, overheating, overtemperature

Delay, overcurrent, overheating, overtemperature, phase   sequence, phase loss protection

Delay, overcurrent, overheating, overtemperature, phase   sequence, phase loss protection

Display

LCD   display, key operation

LCD   display, key operation

LCD   display, key operation

LCD   display, key operation

Temperature control accuracy

±1

±1

±1

±1

Sensor

PT100

PT100

PT100

PT100

Total power

4203W

4203W

5305W

7510W

Heating power

3000W

3000W

3000W

3000W

[Compressor]Specification

Totally   closed

Totally   closed

Totally   closed

Totally   closed

[Compressor]Quantity

1

1

1

2

[Compressor]Power

1103W

1103W

2205W

4410W

[Compressor]Cooling capacity

3486W

3486W

6972W

13944W

[Circulation pump]Power

100W

100W

100W

100W

[Circulation pump]Head

4-6M

4-6M

4-6M

4-6M

[Circulation pump]Flow

20-40L/min

20-40L/min

20-40L/min

20-40L/min

[Circulation pump]Pressure

≤0.4MPa

≤0.4MPa

≤0.4MPa

≤0.4MPa

Refrigerant

R22

R22

R22

R22

Body material

Cold   plate spray anti-corrosion

Cold   plate spray anti-corrosion

Cold   plate spray anti-corrosion

Cold   plate spray anti-corrosion

Outer loop interface

4   points wire mouth with 4 points × 2 meters metal circulation pipe two

4   points wire mouth with 4 points × 2 meters metal circulation pipe two

4   points wire mouth with 4 points × 2 meters metal circulation pipe two

4   points wire mouth with 4 points × 2 meters metal circulation pipe two

Circulating fluid

Grade   A Silicone Oil

Grade   A Silicone Oil

Grade   A Silicone Oil

Grade   A Silicone Oil

Machine size  (LxWxH)

640×570×870mm

640×570×870mm

640×570×870mm

804×703×900mm

Machine net weight

105KG

105KG

115KG

/

Package weight

121KG

121KG

131KG

/
