DESCRIPTION
It is specially designed for drying heat-sensitive, easy-to-decompose, easy-to-oxidize substances, and can be filled with inert gas.
It is specially designed for drying heat-sensitive, easy-to-decompose, easy-to-oxidize substances, and can be filled with inert gas.
1. The cabinet adopts explosion-proof type, the equipment and electrical appliances adopt overall explosion-proof technology, explosion-proof control box, centralized protection, and prevent leakage of unsafe factors such as high temperature, static electricity, and sparks.
2. This equipment is mainly composed of drying box, explosion-proof heating system, explosion-proof electrical control and other parts
3. The inner liner of the box is made of brushed stainless steel, the outer shell is made of high-quality steel plate, the shape is beautiful and generous, and the inner liner is easy to clean
4. The inner tank is equipped with an explosion-proof 304 heating tube heating method, and there is no live element in the box, which is safe and reliable.
5. LCD multi-data full-screen operation display, power failure memory, power failure compensation
6. Convenient operation, fixed value operation, timing operation, automatic stop, scheduled start
7. The exposed connecting wires are all made of explosion-proof flexible connecting tube sets to isolate static sparks and temperature leakage, ensuring safety
8. Explosion-proof grade: Ex d e mb IIB T4 Gb
9. Security: Overheating alarm, menu lock, overheating prevention.
Model | LEX-52LU | LEX-91LU |
Method | Decompression, four-wall heating | |
Operating temperature range | RT+10-250℃ | |
Ultimate vacuum | <133PA | |
Temperature resolution | 0.1℃ | |
Temperature fluctuation | ±1℃ | |
Heating time | 100 minutes/120 minutes | |
Interior | stainless steel | |
Exterior | cold plate spraying | |
Thermal insulation material | aluminum silicate fiber | |
Heater | Stainless steel heating tube heating on all sides (explosion-proof qualification) | |
Observation window | bulletproof tempered glass | |
Vacuum gauge | pointer type | |
Rated power | 1.4kw | 2.0kw |
Temperature control mode | LCD display dual column PID control | |
Temperature display method | LCD upper display; set temperature display: LCD lower display | |
Timer | 0-9999 minutes (hours), timing function can be selected (no, constant temperature timing, running timing | |
Operation function | Fixed value operation, timing operation, automatic stop, scheduled start | |
Program mode | Optional | |
External connection line protection | use explosion-proof flexible connection tube set (explosion-proof qualification) | |
Sensor | Explosion-proof armored PT100 (explosion-proof qualification) | |
Additional functions | deviation correction, menu key lock, power failure memory, overheating preventer | |
Explosion-proof grade | Ex d e mb IIB T4 Gb | |
Internal dimensions (mm) | 415*370*340 | 450*450*450 |
External dimensions (mm) | 600*562*691 | 640*642*796 |
Outer packaging size (mm) | 734*775*818 | 769*855*923 |
Inner volume | 52L | 91L |
Shelf load-bearing capacity | 15 kg | |
Number of clapboard layers | 2 layers | |
Space between shelf | 140mm | 185mm |
Suction port | φ10 mm | |
Exhaust port | φ10 mm | |
Power supply (50/60Hz) rated current | AC220V/6.3A | |
Net weight/Gross weight | 67/92kg | 82/105kg |
Accessories | All aluminum shelf: 2 pieces | |
Optional | Explosion-proof grille, explosion-proof hinge, explosion-proof pressure relief door, explosion-proof seven-inch touch screen instrument (with curve, program function), explosion-proof mouse, partition, vacuum pump |
