DESCRIPTION
JUPITER series microwave digestion/extraction workstation, integrated with the latest industrial technology and materials set a new example in the company, which together with MASTER series, forms the company's complete product line to meet the needs of various industries and strive to provide customers the safety, convenient, efficient, durable products and experience.
Quantified vertical blast/safety bolt design, ensures samples be closed completely and triggera quantified pressure relief while over pressure; safety bolt (patent) unit,instead of safety membraneand other consumables, ensure the digestion vesselbe sealed completely under normal working conditions. And only when thepressure is large enough and may constitute a danger to the safety, the safetybolt will automatically blow out vertically and the cover auto-up to releasethe pressure, achieving quantified vertical blast pressure-relief to guaranteeits well operation. Under normal operation, the safety bolt won’t blow out andrequires no replacement. In addition, it is easy for venting to open the coverafter completion of digestion.
FEATURES
1. Satisfy the requirements of different samples' digestion / extraction processing;
2. Up to 12 vessels high-throughput processing capacity;
3. Exclusive patented multifunctional safety bolt design, instead of explosion-proof membrane and other consumables
4. Aerospace composite fiber outer vessel-the highest level of security measures;
5. Large-screen color software interface, clear and direct-viewing in operation, bright in appearance and smart in performance.
6. Connected to and controlled by computer, achieving secure remote operation, and unlimited program storage database;
7. Small volume VS big chamber, which is advance in industrial design and provides perfect experience;
SPECIFICATIONS
Model | JUPITER |
Power | 220-240 VAC 50/60Hz 8A |
Microwave frequency | 2450MHz |
Installed power | 1800W |
Maximum output power | 1300W，non-pulse continuous automatic variable frequency control |
Turntable design | Load 12 JP-100 closed digestion vessels at same time (standard configuration is 10 vessels |
Pressure measurement and control system | Piezoelectric crystal pressure sensor, pressure control range :0-10MPa (1500 psi), accuracy ± 0.01MPa |
Temperature measurement and control system | High-precision platinum resistor temperature sensor, temperature range:0-300°C, accuracy ±1℃ |
Outer vessel material | Explosion-proof outer vessel made of aerospace composite fiber |
Inner vessel material | Modified TFM material |
Software | JUPITER-A apply JSs software. 5 inch color screen display, USB connection, can save unlimited amount of digestion solution. Simplified JUPITER-B apply JSb software。5 inch screen display and up to 50 methods can be stored。 |
Chamber exhaust system | High-power anticorrosion axial fan, exhaust speed: 3.1 m3/min |
Operating ambient temperature | 0-40 °C |
Working environment humidity | 15-80%RH |
Whole physical size | 450*600*620mm (Width x Depth x Height) |
Net weight | 42 KG |
JP-100 and JK-100 digestion tank specifications
Applicable models | JUPITER BC | JUPITER BF |
Reaction tank model | JK-100 | JP-100 |
Batch volume | Standard 10 digits, can be increased to 12 digits | Standard 10 digits, can be increased to 12 digits |
Inner tube material | TFM | TFM |
Outer tank material | Aerospace composite fiber | Aerospace composite fiber |
Rotor frame structure | Alloy turntable integrated frame | Independent frame |
Reaction tank volume | 100ml | 100ml |
Maximum design pressure | 15Mpa(2200psi) | 15Mpa(2200psi) |
Maximum design temperature | 300℃ | 300℃ |
Photo |
|
|
